Description
| Brand | Asus |
| Model | 4G-AC53U | 90IG04A1-BO3000 |
| Product | router |
| EAN | 4712900709896, 4712900925203 |
| Language | English |
| Filetype | EN – 127 Manual (PDF), EN – 126 Manual (PDF), EN – 3 Manual (PDF), EN – 52 (PDF) |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) | 733 Mbit/s |
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| 3G | Yes |
| 4G | Yes |
| 3G standards | HSPA+ |
| 4G standard | LTE |
| 4G bands supported | 800,1800,2100,2600 MHz |
| UMTS bands supported | 900,2100 MHz |
| Mobile network generation | 4G |
| Antennas quantity | 2 |
| Memory card slot(s) | No |
| USB port | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 1 |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA-Enterprise, WPA2-Enterprise, WPA2-PSK |
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| VPN support | PPTP, OpenVPN, L2TP |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| 3G/4G USB modem compatibility | No |
| SIM card slot | Yes |
| Ethernet WAN | Yes |
| DSL WAN | No |
| WPS push button | Yes |
| Web-based management | Yes |
| Reset button | Yes |
| Power source type | AC |
| AC input voltage | 110 – 240 V |
| AC input frequency | 50 – 60 Hz |
| Output voltage | 12 V |
| Output current | 2 A |
| Windows operating systems supported | Windows 10, Windows 8.1, Windows ME, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
| Linux operating systems supported | Yes |
| Mac compatibility | Yes |
| Mac operating systems supported | Mac OS X 10.1 Puma, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion |
| Width | 137 mm |
| Depth | 118 mm |
| Height | 58 mm |
| Weight | 285 g |
| Operating temperature (T-T) | 0 – 40 °C |
| Storage temperature (T-T) | 0 – 70 °C |
| Operating relative humidity (H-H) | 50 – 90 % |
| Storage relative humidity (H-H) | 20 – 90 % |
