Description
BATTERY INFO
Capacity:
2,048Wh (51.2V, 40Ah)
Type:
LiFePO4 (Lithium Iron Phosphate)
Life Cycles:
3,500+ Cycles to 80% Original Capacity
Shelf-life:
Recharge to 80% Every 3-6 Months
Management System:
MPPT Controller, BMS, etc
OUTPUT
AC Outlets:
4 x 220V-240V,2200W In Total
Inverter Type:
Pure Sine Wave
Surge Power:
4800W
USB-C Port:
1 x 100W Max.
USB-A Port:
2 x 5V/3A USB-A
2 x 18W USB-A
2 x 18W USB-A
12V DC Outlets:
1 x 12V/30A (RV Outlet)
1 x 12V/10A (Car Outlet)
2 x 12V/10A DC 5521 (5.5mm Outlet)
*All Regulated.
1 x 12V/10A (Car Outlet)
2 x 12V/10A DC 5521 (5.5mm Outlet)
*All Regulated.
Wireless Charging Pad:
2 x 15W Max. (For Each)
INPUT
AC Adapter Input:
500W.
Solar Input:
900W Max., VOC 10-145VDC, 15A
Car Input:
12/24V from Cigarette Lighter Port
Max Input:
1,400W, with AC+Solar Input
RECHARGE TIME
AC Adapter (500W):
≈5.5~6 Hours
Solar (900W):
≈3~3.5 Hours (With prime sunshine, ideal orientation and low temperature)
12V/24V Car Outlet (100W/200W):
≈10 or 20 Hours
AC Adapter + Solar (1400W):
≈2.0~2.5 Hours (With prime sunshine, ideal orientation and low temperature)
Dual AC Adapters (1000W):
≈3~3.5 Hours (Extra adapter is REQUIRED)
GENERAL
Scalability:
Expandable w/ Up to 2 x B230 or 2 x B300
Pass-through Charging:
Yes
Weight:
61.9lbs (28.1kg)
Dimensions (LxWxD):
16.5 x 11 x 15.2in ( 42 x 28 x 38.65cm)
Operating Temperature:
-4-104℉ (-20-40℃)
Storage Temperature:
14-113℉ (-10-45℃)
Certifications:
UL Standard, CEC, DOE, FCC, CA Prop 65
