Description
POWER
Power:
120W
Lamination:
ETFE (Ethylene tetrafluoroethylene)
Cell Type:
Monocrystalline Silicon
Cell Efficiency:
Up to 23.4%
Voltage at Max Power(Vmp):
19.6V
Current at Max Power(Imp):
6.1A
Open Circuit Voltage(OCV):
24.8V
Short Circuit Current(Isc):
6.43A
GENERAL
Connector:
Standard MC4 Connector
Weight:
14.9lbs (6.8kg)
Dimensions (Unfolded):
21.7 × 68.8in (55.2 × 174.9cm)
Dimensions (Folded):
21.7 × 18.1in (55.2 × 46.1cm)
Operating Temperature:
14-149℉ (-10-65℃)
Best Working Temperature:
77℉ (25℃)
Cable Length:
118in (3m)
Certifications:
FCC, CE, ROHS
