Description
This is the product description. You can find more details in the following link:
Specifications
Throughput1 86 Gbps
Forwarding Rate in Mpps (64 Byte Packets) 120
10/100/1000 Ports 8
2.5 G Ports 6
Uplink Ports 2 SFP+
PoE+ Enabled Ports (802.3af/at) 14
Serial Console ✔
USB ✔
Out-of-Band Management Port ✔
Rack Mount Kit ✔
Internal Fans 2
Reset Button ✔
MAC Address Table Size 16K
Flash Storage 128 MB
DRAM 512 MB
VLANs 4K
Port Based VLANs 4K
LACP/Trunking 8 LAGs/8 links per LAG
QoS Priority Queues 8
PVRST 32
Ingress/Egress ACL 128
Static ARP Entries 512
ARP Entries 512
Static Routes 64
Dynamic Routing 512
IGMP Multicast Groups 256
Policy Based Automation ✔
Hardware Specifications
Power Supply 100-240 VAC
Max Switch Power (WITH TRAFFIC) 26.76 W
MTBF (Hours) 385,242
Weight 3.6 kg (7.93 lb)
Dimensions 44 x 4.4 x 25 cm (17.3 x 1.75 x 9.85 in)
CPU Speed 800 MHz
LEDs Per Port Link/Activity, PoE
PoE+ Power Budget 240 W
PoE+ Voltage 54 V
