Description
Specifications
| Details | |
|---|---|
| Product code | CSS318-16G-2S+IN |
| Switch chip model | 98DX2518 |
| Operating System | SwOS |
| Storage size | 16 MB |
| Storage type | FLASH |
| MTBF | Approximately 200’000 hours at 25C |
| Tested ambient temperature | -40°C to 70°C |
Powering
| Details | |
|---|---|
| Number of AC inputs | 1 |
| AC input range | 100-240 |
| Frequency (Hz) | 50-60 |
| Max power consumption | 13 W |
| Max power consumption without attachments | 10 W |
| Cooling type | Passive |
Ethernet
| Details | |
|---|---|
| 10/100/1000 Ethernet ports | 16 |
Fiber
| Details | |
|---|---|
| SFP+ ports | 2 |
Other
| Details | |
|---|---|
| CPU temperature monitor | Yes |
Certification & Approvals
| Details | |
|---|---|
| Certification | CE, EAC, ROHS |
| IP | 20 |
