Description
This is the product description. You can find more details in the following link:
Specifications
Throughput 56 Gbps
Non-Blocking Throughput ✔
Forwarding Rate in Mpps (64 Byte Packets) 120
10/100/1000 Ports 8
2.5 G Ports n/a
Uplink Ports 2 SFP
PoE+ Enabled Ports (802.3af/at) n/a
Serial Console ✔
USB ✔
Out-of-Band Management Port n/a
Rack Mount Kit Optional
Internal Fans Fanless
Reset Button ✔
MAC Address Table Size 16K
Flash Storage 128 MB
DRAM 512 MB
VLANs 4K
Port Based VLANs 4K
LACP/Trunking 8 LAGs/8 links
QoS Priority Queues 8
PVRST 32
Ingress/Egress ACL 128
Static ARP Entries 512
ARP Entries 512
Static Routes 64
Dynamic Routing n/a
IGMP Multicast Groups 256
Policy Based Automation ✔
Hardware Specifications
Power Supply 100-240 VAC
Max Switch Power (WITH TRAFFIC) 9.88 W
MTBF (Hours) 806,354
Weight 1.6 kg (3.5375 lb)
Dimensions 21 x 4.4 x 25 cm (8.26 x 1.75 x 9.85 in)
CPU Speed 800 MHz
LEDs Per Port Link/Activity
PoE+ Power Budget n/a
PoE+ Voltage n/a
