Description
Device Interfaces
1 x RJ45 console port
1 x 10/100/1000 Ethernet (PoE) LAN
factory reset
power input
LEDs
Power/Status
Antennas
2 x dual-band internal antennas
Antenna Gain
3.2 dBi (2.4 GHz), 4.3 dBi (5 GHz)
Maximum Output Power
23 dBm (2.4 GHz), 26 dBm (5 GHz)
Data Signal Rate
Up to 1800 Mbps
Standards
IEEE 802.11a/b/g/n/ac/ax
IEEE 802.3u/ab
IEEE 802.3az
Energy-Efficient Ethernet (EEE)
IEEE 802.3at PoE
Operating Frequency
2.4 – 2.483 GHz, 5.15 – 5.35 GHz, 5.47 – 5.85 GHz
Security Protocol
WPA/WPA2/WPA3โข Personal/Enterprise,
WEP 64/128-bit
SSID broadcast disable
MAC address access control
internal RADIUS server
Network Management
Web (HTTP)
Secure Socket Layer (SSL)
Traffic control
D-Link Nuclias Connect
Power Supply
12 V / 2.5 A (optional power adapter)
IEEE 802.3at PoE
Max. Power Consumption
19.44 W
MTBF
> 30,000 hours
Operating Temperature
0 หC to 40 หC (32 หF to 104 หF)
Storage Temperature
-20หC to 65 หC (-4 หF to 149หF)
Operating Humidity
10% to 90%
Storage Humidity
5% to 95%
Weight
477.4 g (1.05 lb)
Dimensions
170 x 170 x 28 mm (6.69 x 6.69 x 1.1 in)
Certifications
CE, FCC
