A 10 Gigabit SFP+ optical transceiver (10GBASE-LR) for long-reach single-mode links up to 10 km at 1310 nm over duplex-LC fibre. It carries digital diagnostics (DDM, the “-DD” suffix), a 9.5–14.5 dB power budget and a 3.3 V supply, and is hot-pluggable and MSA-compliant across a 0–70 °C range.
| Device Type | 10GBASE-LR single-mode SFP+ transceiver (with DDM) |
|---|---|
| Form Factor | SFP+ |
| Data Rates | 10 Gbps |
| Wavelength | 1310 nm |
| Max Distance | 10 km |
| Connector | Duplex LC |
| Fiber Type | Single-mode (9/125 µm) |
| TX Power | -8 to 0 dBm |
| Receiver Sensitivity | -14.5 dBm |
| Network Standards | IEEE 802.3ae 10GBASE-LR |
| Operating Temperature | 0 to 70 C |
| Brand |
