Description
Ports
โข 24 x SFP ports
โข 2 x 10GBASE-T ports
โข 4 x 10G SFP+ ports
Optional Redundant Power Supply
โข DPS-500A
โข DPS-500DC
Console Port
10/100/1000BASE-T RJ-45 port for out-of-band CLI management
Management Port
10/100/1000BASE-T RJ-45 port for out-of-band IP management
Stacking Ports
4
Stacking Cost
1
USB Ports
1 x USB 2.0 Type A port
Switching Capacity
168 Gbps
64-Byte Packet Forwarding Rate
125 Mpps
Packet Buffer Memory
2 MB
MTBF (Hours)
400,490 hours
Acoustics
โข Max: 52.3 dB
โข Min: 42.7 dB
Heat Dissipation
221.8 BTU/h
Power Input
100 to 240 VAC, 50 to 60 Hz
Max Power Consumption
โข Max.: 65.01 W
โข Standby: 22.77 W
Dimensions (W x D x H)
โข 440 x 250 x 44 mm
โข (17.32 x 9.84 x 1.73 in)
Weight
3.5 kg (7.72 lbs)
Ventilation
3 x Smart fans
Operation Temperature
0 to 50 หC (32 to 122 ยฐF)
Storage Temperature
-40 to 70 หC (-40 to 158 ยฐF)
Operating Humidity
10% to 90% RH
Storage Humidity
5% to 90% RH
Emission (EMI)
FCC Class A, CE Class A, VCCI Class A, IC, RCM, BSMI
Safety
CB, cUL, BSM
Warranty
1 year
