Description
Spectrum
Channel Width MHz 20 | 40 | 80 | 160 MHz
Proprietary Physical Layer ePMP air interface with 2×2 MIMO/OFDMA
Channel Spacing Configurable in 5 MHz increments
Frequency Range 5725–7125 MHz1,2
1 Allowable frequencies and bands are dictated by individual country regulations. Operation under AFC (Automatic Frequency
Coordination) control in FCC jurisdictions. 2 Performance of radio from 5725–5925 MHz is TBD.
MAC Layer
(Media Access Control)
Cambium proprietary
Ethernet Interface 100/1000 BaseT, rate auto negotiated, 802.3at compliant; SFP+ port
Protocols Used IPv4/IPV6 , UDP, TCP, IP, ICMP, SNMPv2c, HTTPs, STP, SSH, IGMP snooping
Network Management HTTP/HTTPS, SNMPv1/2, SNMPv3, SSH
VLAN 802.1Q with 802.1p priority
Performance
ARQ Yes
Nominal Receive Sensitivity
(w/FEC) @20 MHz Channel
MCS 0 = -92 dBm to MCS 13
(4096 QAM-5/6) = -53 dBm (per chain)
Nominal Receive Sensitivity
(w/FEC) @40 MHz Channel
MCS 0 = -89 dBm to MCS 13
(4096 QAM-5/6) = -50 dBm (per chain)
Nominal Receive Sensitivity
(w/FEC) @80 MHz Channel
MCS 0 = -86 dBm to MCS 13
(4096 QAM-5/6) = -47 dBm (per chain)
Nominal Receive Sensitivity
(w/FEC) @160 MHz Channel
MCS 0 = -83 dBm to MCS 13
(4096 QAM-5/6) = -44 dBm (per chain)
Modulation Levels (Adaptive) MCS 0 (BPSK) to MCS 13
(4096 QAM-5/6)
Geolocation Integrated GPS with antenna puck
Transmit Power Range +3 to +28 dBm (combined, to regional EIRP limit)
(1 dB interval)
QoS (Quality of Service) Three-level priority (voice, high, low) with packet classification by DSCP, COS, VLAN ID, IP & MAC
Address, broadcast, multicast, and station priority
Physical
Surge Suppression 1 Joule Integrated
Environmental IP67
Temperature -40°C to 55°C (-40°F to 131°F)
Weight 0.73 kg (1.61 lb) without bracket
Dimensions (Dia x Depth) 256 x 125 x 47 mm
(10.1 x 4.9 x 1.9 in)
Pole Diameter Range
Center:
3.1 to 7.6 cm
(1.25 to 3.0 in)
Power Consumption 28W
Input Voltage 44V–59V
Antenna External Dish, 2 x 50 ohm, RP SMA (reverse polarity)
6 GHz Dish: Part # C060900D021A
GPS Antenna Connection 1 x 50 ohm, SMA; external GPS
GPS Puck Antenna: Part # N000900L030A
Security
Encryption 128-bit AES (CCMP mode), 256-bit AES optional, where allowed
Certifications
FCCID Z8H89FT0069
FCC Regulatory Part # C068940P151A
ETSI Regulatory Part # C060940P051A
Industry Canada Cert 109W-0069
CE Visit cambiumnetworks.com for declaration of conformity
