Description
Technology
Print mode
Impact matrix
Number of needles
24 needles
Number of columns
136 Columns
Needles
24 needles
Impression
Print speed
LQ: 10 cpi: 120 chars/sec, 12 cpi: 144 chars/sec, High-speed draft: 10 cpi: 480 chars/sec, 12 cpi: 576 chars/sec, Draft: 10 cpi: 360 chars/sec, 12 cpi: 432 chars/sec
Perforations
5 plus one original
Print resolution
360 x 180 DPI (ppi)
Connectivity
Connections
USB 2.0, Ethernet interface (100 Base-TX/10 Base-T) (optional), Type B interface, Bidirectional parallel, RS-232 (optional)
Paper management
Paper feed
Single sheet front and back, Continuous paper front and back, Paper output back
Paper sizes
Sheet paper (single or multi-ply), Endless paper (single or multi-ply), Labels (single or multi-ply), Roll paper, Envelopes, Cardboard
General information
Energy consumption
46 W, 3 W (economy)
Product dimensions
693 x 405 x 268 mm (Width x Depth x Height)
Product weight
13 kg
Temperature
operating temperature 5°C – 35°C
Air humidity
operation 10% – 80%
Compatible operating systems
Windows 2000, Windows 7, Windows 8, Windows 98, Windows Vista, Windows XP, Windows XP x64
Software included
Epson Status Monitor
Mean Time Between Failures
20,000 Hours
Printhead life
400 million impacts per needle
Sound pressure
Operation: 54 dB(A)
Memory
128 kB Included
Ribbon yield
15000000 Characters Black Draft
Other settings:
Emulations
ESC/P2, IBM PPDS
