Description
Print type
Print method
Serial impact dot matrix
Print method receipt
Serial impact dot matrix
Technology
Serial Impact Dot Matrix
Printing Font
Traditional Chinese, Simplified Chinese, Japanese, Korean
Character set
95 Alphanumeric, 48 International, 128 x 12 Graphic, Traditional / Simplified Chinese, Korean, Thai, Japanese
Print Language
ePOS
Fonts & Styles
Print Speed
4,70 lps (40 columns, 16,00 cpi), 0,00 ~ 0,00 lps, 0 / 0 cps
Print Speed (label)
0,00 ~ 0,00 lps, 0 / 0 cps
Print Speed (peeler mode)
0,00 ~ 0,00 lps, 0 / 0 cps
Print Speed character
0,00 ~ 0,00 lps, 0 / 0 cps, 0,00 lps (0 mm paper width)
Print Speed graphic
0,00 ~ 0,00 lps, 0 / 0 cps
Print Speed receipt
0,00 ~ 0,00 lps, 0 / 0 cps
Print Speed slip
0,00 ~ 0,00 lps, 0 / 0 cps
Print Speed endorsement
0,00 ~ 0,00 lps, 0 / 0 cps
Printing Font Receipt
ANK, Traditional Chinese, Simplified Chinese
Paper
Paper Types
Roll
Paper size ASF
Min 0 – 0 mm
Paper size endorsement
Min 0 – 0 mm
Paper size manual feed
Min 0 – 0 mm
Paper size roll paper
76,00 ± 0,50 (W) mm x dia 83,00 mm,
69,50 ± 0,50 (W) mm x dia 83,00 mm,
57,50 ± 0,50 (W) mm x dia 83,00 mm
Paper size sheet
Min 0 – 0 mm
Paper size slip
Min 0 – 0 mm
Paper size validation
Min 0 – 0 mm
Interfaces
Interfaces
RS-232, Drawer kick-out
data buffer
Data Buffer
20 kB or 40 Bytes, ,
Power
Power Supply
AC adapter, C1
Operating Voltage
24 V
General
Product dimensions
160 x 248 x 139 mm (Width x Depth x Height)
Product weight
2,5 kg
Autocutter
Yes Included
Colour
Epson Dark Grey
Noise Level
Operation (Roll):64 dB (A)
Power consumption
Printing: Appx.31 W, Standby: Appx.2 W
Power Supply
AC adapter, C1
Supported Humidity
Operation 10% – 90%, Storage 10% – 90%
Supported Temperature
Storage -10° C – 50° C
Reliability
Reliability
18.000.000 MCBF (Lines), 180.000 MTBF (Hours)
Auto Cutter Life
800.000 Cuts
Print Head Life
150 Mio Characters
Other Features
Cutter
Partial Cut
Factory options
Autocutter, Near-end sensor
