Description
General Specifications
| Attribute | Details |
|---|---|
| Launch Date | Q4’23 |
| Status | Launched |
| Market | PC / Client / Workstation |
| Socket | FCLGA1700 |
| TDP (Base Power) | 125 W |
| Max Turbo Power | 253 W |
| Max Operating Temp (Tjunction) | 100°C |
| Package Size | 45.0 mm x 37.5 mm |
Core Architecture
| Total Cores | 20 |
|---|---|
| Performance Cores (P-cores) | 8 |
| Efficient Cores (E-cores) | 12 |
| Total Threads | 28 |
Frequencies
| Attribute | Frequency |
|---|---|
| P-core Base Frequency | 3.4 GHz |
| E-core Base Frequency | 2.5 GHz |
| Max Turbo Frequency | 5.6 GHz |
| Turbo Boost Max Technology 3.0 | 5.6 GHz |
| P-core Max Turbo Frequency | 5.5 GHz |
| E-core Max Turbo Frequency | 4.3 GHz |
Cache
| Smart Cache (L3) | 33 MB |
|---|---|
| Total L2 Cache | 28 MB |
Memory
| Attribute | Details |
|---|---|
| Max Memory Size | 192 GB |
| Memory Types Supported | DDR5-5600, DDR4-3200 |
| Memory Channels | 2 |
| Max Memory Bandwidth | 89.6 GB/s |
| ECC Memory Support | Yes |
Integrated Graphics
| GPU | Intel® UHD Graphics 770 |
|---|---|
| Base Frequency | 300 MHz |
| Max Dynamic Frequency | 1.6 GHz |
| Execution Units | 32 |
| Max Displays Supported | 4 |
| Graphics Output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
| Max Resolution (HDMI) | 4096 x 2160 @ 60Hz |
| Max Resolution (DP) | 7680 x 4320 @ 60Hz |
| Max Resolution (eDP) | 5120 x 3200 @ 120Hz |
| DirectX / OpenGL / OpenCL | 12 / 4.5 / 3.0 |
Expansion Options
| PCIe Revision | 5.0 and 4.0 |
|---|---|
| Max PCIe Lanes | 20 |
| PCIe Configurations | Up to 1×16+4, 2×8+4 |
| DMI Revision / Lanes | 4.0 / 8 |
Advanced Technologies
-
Intel® Hyper-Threading Technology
-
Intel® Turbo Boost 2.0 & 3.0
-
Intel® Thread Director
-
Intel® Deep Learning Boost
-
Intel® Speed Shift, SpeedStep
-
Intel® Gaussian & Neural Accelerator 3.0
-
Intel® Volume Management Device (VMD)
Security & Virtualization
-
Intel vPro® Enterprise, Essentials, Platform
-
Intel® AES-NI, Secure Key, OS Guard, Boot Guard
-
Intel® Trusted Execution Technology
-
Intel® Software Guard Extensions (SGX)
-
Intel® Control-Flow Enforcement Technology
-
Intel® Virtualization (VT-x, VT-d, VT-x with EPT, VT-rp)
-
Intel® Total Memory Encryption (TME)
-
Intel® Hardware Shield Eligibility
