Description
General Information
| Attribute | Details |
|---|---|
| Launch Date | Q4’17 |
| Status | Launched (ESU ends: June 30, 2025) |
| Socket | FCLGA1151 |
| TDP | 65 W |
| Max Operating Temp (TJUNCTION) | 100°C |
| Use Conditions | PC / Client / Tablet |
Core Architecture
| Total Cores | 6 |
|---|---|
| Total Threads | 12 |
| Base Frequency | 3.20 GHz |
| Max Turbo Frequency | 4.60 GHz |
| Cache (L3) | 12 MB Intel® Smart Cache |
| Bus Speed | 8 GT/s |
Memory Support
| Max Memory Size | 128 GB |
|---|---|
| Memory Types | DDR4-2666 |
| Memory Channels | 2 |
| Max Memory Bandwidth | 41.6 GB/s |
| ECC Memory Support | No |
Integrated Graphics
| GPU Name | Intel® UHD Graphics 630 |
|---|---|
| Base Frequency | 350 MHz |
| Max Dynamic Frequency | 1.20 GHz |
| 4K Support | Yes @ 60Hz |
| Max Displays Supported | 3 |
| Max Resolution (DP/eDP) | 4096×2304 @ 60Hz |
| DirectX/OpenGL Support | 12 / 4.5 |
Expansion & I/O
| PCI Express Revision | 3.0 |
|---|---|
| PCIe Configurations | 1×16, 2×8, 1×8+2×4 |
| Max PCIe Lanes | 16 |
Package Details
| Package Size | 37.5 mm x 37.5 mm |
|---|---|
| Thermal Solution Spec | PCG 2015C (65W) |
| Max CPU Configuration | 1 |
Advanced Technologies
-
Intel® Turbo Boost Technology 2.0
-
Intel® Hyper-Threading Technology
-
Intel® Optane™ Memory Support
-
Transactional Synchronization Extensions
-
Intel® SpeedStep®, Thermal Monitoring
-
Intel® SGX, MPX, Boot Guard, SIPP
-
Instruction Set: 64-bit
-
Instruction Set Extensions: SSE4.1, SSE4.2, AVX2
Security & Virtualization
-
Intel® AES-NI, Secure Key, OS Guard
-
Intel® Virtualization Technology (VT-x, VT-d, EPT)
-
Intel® Trusted Execution Technology
-
Intel® Identity Protection Technology
