Description
General Information
| Attribute | Details |
|---|---|
| Launch Date | Q4’2015 |
| Marketing Status | Discontinued |
| End of Servicing Updates | September 30, 2022 |
| Socket | FCLGA1151 |
| Max CPU Configuration | 1 |
| TDP | 80 W |
| Package Size | 37.5mm x 37.5mm |
| Embedded Options Available | No |
Performance
| Attribute | Details |
|---|---|
| Total Cores | 4 |
| Total Threads | 4 |
| Base Frequency | 3.00 GHz |
| Max Turbo Frequency | 3.50 GHz |
| Intel® Turbo Boost | 2.0 |
| Cache | 8 MB Intel® Smart Cache |
| Bus Speed | 8 GT/s |
Memory Specifications
| Attribute | Details |
|---|---|
| Max Memory Size | 64 GB |
| Memory Types | DDR4-1866/2133, DDR3L-1333/1600 |
| Voltage | 1.35V |
| Max Memory Channels | 2 |
| Max Memory Bandwidth | 34.1 GB/s |
| ECC Memory Supported | Yes |
Graphics Specifications
| Attribute | Details |
|---|---|
| Integrated Graphics | None |
| 4K Support | No |
| Displays Supported | 0 |
| Intel® Quick Sync Video | No |
| Intel® Clear Video HD/3D/etc. | No |
Expansion Options
| Attribute | Details |
|---|---|
| Scalability | 1S Only |
| PCI Express Revision | 3.0 |
| PCIe Configurations | 1×16, 2×8, 1×8+2×4 |
| Max PCI Express Lanes | 16 |
Advanced Technologies
| Technology | Supported |
|---|---|
| Intel® Hyper-Threading Technology | No |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® 64 | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | SSE4.1, SSE4.2, AVX2 |
| Idle States | Yes |
| Enhanced Intel SpeedStep® Technology | Yes |
| Thermal Monitoring Technologies | Yes |
Security & Virtualization
| Feature | Supported |
|---|---|
| Intel vPro® Platform | Yes |
| Intel® AES New Instructions | Yes |
| Intel® Secure Key | Yes |
| Intel® SGX (with Intel® SPS and ME) | Yes |
| Intel® MPX | Yes |
| Intel® OS Guard | Yes |
| Intel® Boot Guard | Yes |
| Intel® Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel® Virtualization Technology (VT-x) | Yes |
| Intel® Virtualization Technology for Directed I/O | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
