Description
General Information
| Attribute | Details |
|---|---|
| Launch Date | Q1’2012 |
| Discontinued | Q2’2015 |
| Servicing End Date | June 30, 2020 |
| Marketing Status | Discontinued |
| Socket | FCLGA2011 |
| Package Size | 52.5mm x 45.0mm |
| Max CPU Configuration | 2 CPUs |
| TDP | 80 W |
| Tcase Max | 70.0°C |
| Embedded Options Available | No |
| Scalability | 2S Only |
Performance
| Attribute | Details |
|---|---|
| Total Cores | 4 |
| Total Threads | 4 |
| Base Frequency | 1.80 GHz |
| Turbo Boost | No |
| Cache | 10 MB Intel® Smart Cache |
| QPI Links | 2 |
| Bus Speed | 6.4 GT/s |
Memory Specifications
| Attribute | Details |
|---|---|
| Max Memory Size | 384 GB |
| Memory Types | DDR3-800 / DDR3-1066 |
| Memory Channels | 4 |
| Max Memory Bandwidth | 34.1 GB/s |
| ECC Support | Yes |
Expansion Options
| Attribute | Details |
|---|---|
| PCI Express Revision | 3.0 |
| Max PCI Express Lanes | 40 |
Advanced Technologies
| Technology | Supported |
|---|---|
| Intel® 64 | Yes |
| Intel® AVX | Yes |
| Instruction Set | 64-bit |
| Idle States | Yes |
| Enhanced Intel SpeedStep® Technology | Yes |
| Intel® Demand Based Switching | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Flex Memory Access | No |
| Intel® Identity Protection Technology | No |
Security & Virtualization
| Feature | Supported |
|---|---|
| Intel vPro® Platform | Yes |
| Intel® AES New Instructions | Yes |
| Intel® Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel® Virtualization Technology (VT-x) | Yes |
| Intel® VT-d (Directed I/O) | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
