Description
General Information
| Attribute | Details |
|---|---|
| Launch Date | Q1’2012 |
| Status | Discontinued |
| End of Updates | June 30, 2020 |
| Socket | FCLGA2011 |
| Package Size | 52.5mm x 45.0mm |
| Max CPU Configuration | 2 CPUs |
| TDP | 115 W |
| Tcase Max | 80°C |
| Embedded Options Available | No |
| Scalability | 2S Only |
Performance
| Attribute | Details |
|---|---|
| Total Cores | 8 |
| Total Threads | 16 |
| Base Frequency | 2.60 GHz |
| Max Turbo Frequency | 3.30 GHz |
| Intel® Turbo Boost 2.0 | Yes |
| Cache | 20 MB Intel® Smart Cache |
| Bus Speed | 8 GT/s |
| QPI Links | 2 |
Memory Specifications
| Attribute | Details |
|---|---|
| Max Memory Size | 384 GB |
| Memory Types | DDR3 800/1066/1333/1600 |
| Max Memory Channels | 4 |
| Max Memory Bandwidth | 51.2 GB/s |
| ECC Memory Support | Yes |
Expansion Options
| Attribute | Details |
|---|---|
| PCI Express Revision | 3.0 |
| Max PCI Express Lanes | 40 |
Advanced Technologies
| Feature | Supported |
|---|---|
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper-Threading Technology | Yes |
| Intel® 64 | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® AVX |
| Idle States | Yes |
| Enhanced Intel SpeedStep® Technology | Yes |
| Intel® Demand Based Switching | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Flex Memory Access | No |
| Intel® Identity Protection Technology | No |
Security & Virtualization
| Feature | Supported |
|---|---|
| Intel vPro® Platform | Yes |
| Intel® AES New Instructions | Yes |
| Intel® Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel® Virtualization Technology (VT-x) | Yes |
| Intel® Virtualization Technology for Directed I/O | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
