Description
| Parameter | Specification |
|---|---|
| Connector Type | LC/APC to LC/APC (Duplex) |
| Fiber Mode | OS2 Single Mode 9/125 μm (G.652.D / G.657.A1 / G.657.A2 optional) |
| Polish Type | APC (Angled Physical Contact, 8° angle) |
| Cable Type | Duplex |
| Cable Diameter | 2.0 mm or 3.0 mm (per leg) |
| Cable Jacket Material | PVC, LSZH, OFNR, or OFNP (UL listed options) |
| Jacket Color | Yellow (standard for OS2) |
| Insertion Loss | ≤ 0.25 dB (typical ≤ 0.2 dB) |
| Return Loss | ≥ 60 dB (APC) |
| Operating Wavelength | 1310 nm / 1550 nm |
| Fiber Count | Duplex (2 fibers) |
| Bend Radius (Installation) | ≥ 30 mm |
| Bend Radius (Long Term) | ≥ 10 mm |
| Operating Temperature | –40°C to +75°C |
| Storage Temperature | –45°C to +85°C |
| Compliance Standards | RoHS, IEC 61754-20, TIA/EIA-568-C.3, ISO/IEC 11801 |
| End-Face Quality | 100% interferometer tested |
| Boot Type | Short/standard/long (color-coded available) |
