Description
Model:
Model: MX 3K
Rating: 3000VA
Output power: 2700W
Input:
Voltage: 220V, 230V, 240V, 1ะค2wires
Frequency: 40Hz – 70 Hz
Voltage range: 160-300 VAC @ 100% load; 110-300 VAC @ 50% load
Power Factor: >99%
THDi: <4%
Output:
Voltage (on battery): 220V, 230V, 240V, +/-1% (selectable output voltage), 1ร 2Wires
Frequency (on battery): 50/60 Hz +/-0.1%
Transfer Time: 0 ms
UPS Design Technology: On-Line / Fully digitized microprocessor controlled
Output Wave Form: Pure Sine wave
Total Harmonic distortion (THD): < 2% of THD at linear load, < 4% THD at nonlinear load
Crest Factor: 3:1
Protection:
Overload Protection: 110% for 10 minutes and 130% for 1 minute>130% for 1 sec
Short Circuit Protection: UPS output cut off immediately using input fuse/circuit breaker protection
System Display:
LED indicators: Sixteen Leds indicating UPS status, Load level, Battery level, Overload, Fault, and programmable outlet information
LCD indicators: UPS Status, Load level, Battery level, Input/Output voltage, Discharge time, and Fault indicators
Battery:
Battery Type: Sealed, maintenance-free lead acid batteries, 3-5 years typical life time
Typical Recharge Time: 4 hours to 90% Full capacity
Charging Current (A): 1.5
Battery number (Pcs): 72
Back up time (1/2 Load): 18 min
Audible Alarm:
Battery mode: Beep every 4 second
Low battery: Beep every second
Overload: Beep twice every second
Fault: Continuously beeping
Communication:
USB, RS-232: Interface with power management software
SNMP, AS-400: Power Management from SNMP manager and web browser
Compatibility: Supports Windows family, Linux, Unix, and Mac
Physical:
W x D x H (mm): 190 x 421 x 318
Net Weight (kgs): 28
Efficiency:
AC Mode: 95.5%
Battery Mode:93%
Environment:
Ambient operation: Maximum elevation at 3500m, 0 to 40หC, 0 to 95% humidity (non-condensing)
Audible noise: <50dBA at 1 Meter
Standards & Certifications:
Safety: UL 1778, CE, EN 50091-1, EN 60950 (RD/), IEC 60950
Performance: EN50091-3/IEC 62040-3
EMC (EMS / EMI): IEC 61000-4-2/-3/-4/-5/-6/-8/-11, IEC 61000-3-2/-3, FCC Part 15, CISPR 22, EN 50091-2/IEC62040-2 Class A, EN 55022/B, FCC 47 part 15 – Subpart B –
Design, production, and services: ISO 9001
Environment: ISO 14001 certified company
Marking & Certifications: CE, TUV/GS, UL, cUL, c-Tick
