Description
UTPUT CONNECTORS
- 24-pin ATX power:1
- 4+4-pin CPU power:2
- 6+2-pin PCIe power:6
- SATA power:6
- Peripherals:6
CABLE SPECS
- 24-pin ATX power:600 mm, Nylon sleeving
- 4+4-pin CPU power:700 mm, Nylon sleeving
- 6+2-pin PCIe power:650 + 150 mm, Nylon sleeving
- SATA power:500 + 150 mm
- Peripherals:500 + 150 mm
AC INPUT RATING
- 100 – 240Vac:10A-5A 50Hz-60Hz
DC OUTPUT RATING
- +3.3V and +5V:22A (120W)
- +12V:70.8A (850W)
- -12V:0.3A (3.6W)
- 5Vsb:3A (15W)
- Total:850W
OPERATION
- PF Correction:Active @0.96
- MTBF:100,000 hours
- Temperature:0 – 50 °C (derating from 100% to 80% from 40 °C to 50 °C)
ENERGY EFFICIENCY
- Rating:80 Plus Gold
- 20% loading:89.71% @115Vac
- 50% loading:90.80% @115Vac
- 100% loading:88.03% @115Vac
FAN SPECS
- Dimensions:135 x 135 x 25 mm
- Speed:0-2300 ± 10% RPM
- Airflow:93.02 CFM (Tpy.)
- Noise:44.5 dBA max
- Bearing:Fluid Dynamic Bearing (FDB)
GENERAL
- Dimensions:150 x 150 x 86mm
- Material(s):Steel, PCB and Plastic
- Compliance Standard:ATX12V v2.52 / EPS12V v2.92
- Regulation & Certification:cTUV-SUDus / CUL (UL60950/62368-1) / TUV / (EN60950/62368-1) / CB/ (IEC 950/62368-1) / CCC / CEC /BSMI / RCM / EAC / CE / LVD / UKCA
- Warranty:10 years
- Model Number:PA-8G1BB
UPC
- UPC (TW):815671017383
- UPC (CN):815671017314
- UPC (AR):815671017321
- UPC (US):815671017338
- UPC (EU):815671017345
- UPC (UK):815671017352
- UPC (AU):815671017369
- UPC (JP):815671017376
- UPC (WO):815671017406
- UPC (IN):815671017390
EAN
- EAN (TW):5060301697694
- EAN (CN):5060301697625
- EAN (AR):5060301697632
- EAN (US):5060301697649
- EAN (EU):5060301697656
- EAN (UK):5060301697663
- EAN (AU):5060301697670
- EAN (JP):5060301697687
- EAN (WO):5060301697717
- EAN (IN):5060301697700
