QNAP 4-bay 3.5" SATA HDD USB 3.0 Type-C hardware RAID External Enclosure
QNAP 4-bay 3.5" SATA HDD USB 3.0 Type-C hardware RAID External Enclosure
QNAP · SKU TR-004

QNAP 4-bay 3.5″ SATA HDD USB 3.0 Type-C hardware RAID External Enclosure

Out of stock
QNAP
Same-day delivery
In Beirut · $5 flat
Authorized warranty
Direct from brands
AI-powered search
Finds it even when you can't
Humans on WhatsApp
Mon–Sat 9 AM – 7 PM
  • Brand QNAP

Description

TR-004 Hardware Specs

JBOD Connection Interface USB
Main chip Micro processor with hardware RAID
Drive Bay 4 x 3.5-inch

The system is shipped without HDD.
Drive Compatibility 3.5-inch SATA 3Gb/s slot (supports SATA 6Gb/s hard drives with backward compatibility, performance limited to 3Gb/s)
2.5-inch SATA 3Gb/s slot (supports SATA 6Gb/s hard drives with backward compatibility, performance limited to 3Gb/s)
2.5-inch SATA 3Gb/s slot (supports SATA 6Gb/s solid state drives with backward compatibility, performance limited to 3Gb/s)

You can only use one disk type (HDD or SSD) in a RAID group. Combining different types of disk in one RAID group is not supported.

TR-004 does not support the QDA-A2AR/ QDA-A2MAR.
Hot-swappable
USB 3.2 Gen 1 Port 1 x Type-C USB 3.2 Gen 1 (USB 3.2 Gen 1)
Form Factor Tower
Dimensions (HxWxD) 168.5 × 160.2 × 219 mm

Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model)
Weight (Net) 3.18 kg
Weight (Gross) 3.18 kg
Operating Temperature 0 – 40 °C (32°F – 104°F)
Storage Temperature -20 – 70°C (-4°F – 158°F)
Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit Minimum 60W adapter (12VDC), 100-240VAC
Power Consumption: HDD Sleep Mode 4.17 W
Power Consumption: Operating Mode, Typical 18.21 W

Tested with drives fully populated.
Fan 1 x 120mm, 12VDC
System Warning Buzzer
Kensington Security Slot

✓
QTS / QuTS hero

✓
Windows

✓
Ubuntu

✓
Mac

✓
Used as Hardware RAID (DAS)

✓
Standard Warranty 2
RAID 10

✓
RAID 5+ Spare

✓
RAID 5

✓
RAID 1

✓
RAID 0

✓
JBOD

✓
Single Disk

✓



TR-004 Software Specs   ✓

System modes Individual, JBOD, hardware RAID 0/1, Software control (Software control requires a QNAP NAS or Windows/macOS utility)

Note: You can only use one disk type (HDD or SSD) in a RAID group. Combining different types of disk in one RAID group is not supported.
Features
  1. Disk modes: Individual, JBOD, RAID 0, RAID 1.
  2. System, fan, and drive failure monitoring with LED and audio alerts.
  3. System sleep* during USB cable disconnection and host device hibernation** or shut down.
    *RAID rebuild delays the sleep.
    **Some hosts may not be supported.
Minimum system requirements QNAP NAS or PC with a USB Type-A or Type-C port
Minimum operating system requirements
  1. QNAP NAS: QTS 4.3.6 (or later)
  2. Windows: Windows 8.1 (or later), Windows Server 2012 R2 (or later)
  3. Mac: macOS X 10.13 (or later)
System fan 5-speed automatic fan control
Software utility Windows/macOS: QNAP External RAID Manager
Supported File Systems NAS storage (EXT4), external hard drive (EXT3, EXT4, NTFS, FAT32, HFS+, and exFAT*)
*Purchase of an exFAT driver license from the License Center is required.
QTS Storage Management Features
  1. General & External Storage Mode
    • Overview device, disks, and RAID info and status
    • Support for disk S.M.A.R.T. monitoring
    • Determine location of enclosure using LEDs and system speakers
    • External RAID software configuration
    • RAID rebuild
    • RAID recovery
    • Firmware update
    • Format partition
    • Erase partition and device
  2. NAS Storage Mode
    • The storage pools and volumes in the expansion enclosures are configured via the QTS operating system.
    • Volume and LUN snapshots – Snapshot Manager
    • Snapshot Cloning – Snapshot Replica – Snapshot Vault
    • Support for Windows Previous Versions (CIFS/SMB)
Software utility Features
  1. QNAP External RAID Manager
    • Overview device, disks, and RAID information and status
    • Support for disk S.M.A.R.T. monitoring
    • Determine location of enclosure using LEDs and system speakers
    • Desktop notifications for device alerts
    • External RAID software configuration
    • RAID rebuild – RAID rebuild speed customization
    • RAID recovery – Firmware update
    • Notifications when new firmware and application versions are available
    • System event logs for troubleshooting
    • Export event logs to .csv file

Note: Actual performance may vary depending on operating environment and other factors, such as RAID mode, RAID configuration, disk model and capacity.
