Description
| Standard&Protocol | IEEE 802.3, IEEE 802.3u, IEEE 802.4ab |
| Ethernet Interface | 2 x 10/100/1000Mbps RJ45 ports per node |
| Antenna | 2 x Internal antenna |
| Button | 1 x Reset Button |
| Power | Input: 100-240V—50/60Hz, 0.6A Output: 12V1A |
| Dimension | 100 x 100 x 100mm (3.94 x 3.94 x 3.94in) |
| LED Indicator | 1 x Tri-color LED Indicator(Green,Yellow,Red) |
| Wireless Standard | IEEE802.11a/b/g/n/ac (WiFi 5 wave 2) |
| Wireless roaming | Comply with IEEE802.11k/v/r |
| Mesh network Standard | IEEE802.11s |
| Rate | 2.4GHz: 300Mbps 5GHz: 867Mbps |
| Frequency | 2.4~2.4835GHz 5.15~5.25GHz 5.725~5.85GHz |
| Transmission Power | CE: <20dBm(2.4G) <23dBm(5G) |
| Basic Features | SSID Broadcast Beam Forming MU-MIMO AP Steering Band Steering |
| Wireless Security | WPA-PSK/WPA2-PSK(default) |
| Operating Mode | Router Mode,Bridge Mode |
| Internet Connection Type | PPPoE, Dynamic IP, Static IP PPPoE(Russia), PPTP(Russia), L2TP(Russia) |
| DHCP Server | DHCP Server, DHCP Client List |
| Virtual Server | Port Forwarding, UPnP |
| Parental Control | Client Filter |
| Firewall | Forbid TCP/UDP flood attack |
| VPN | PPTP/L2TP/IPsec pass through |
| DNS | Support manually setting DNS server |
| Special Features | Smart QoS (Gaming, Video & Audio, Download) |
| Others | Auto-sensing internet connection Support App management and Remote management Guest Network Firmware upgrade online |
| Operation Temperature | 0 ~ 40 ℃ |
| Storage Temperature | -40 ~ 70 ℃ |
| Operating Humidity | 10%~90% RH non-condensing |
| Storage Humidity | 5%~90% RH non-condensing |
| APP installation | Available in iOS 8.0 or later, Android 4.0 or later |
| Certification | CE, FCC, RoHS,EAC,IC |
| Package Contents | Mesh3 x 3, Power adapter x 3, QIG x 1, RJ45 Gigabit Ethernet cable x 1 |
