Description
| HARDWARE FEATURES | |
|---|---|
| Ports | – |
| Button | LED and WPS 2-in-1 Button |
| Input Power | 100-240V~50/60Hz |
| Power Consumption | 23W |
| Antenna | Internal Antennas |
| WIRELESS FEATURES | |
|---|---|
| Wireless Standards | IEEE 802.11a/n/ac/ax 5 GHz, IEEE 802.11b/g/n/ax 2.4 GHz |
| Frequency | 2.4 GHz and 5 GHz |
| Signal Rate | 574 Mbps at 2.4 GHz, 2402 Mbps at 5 GHz |
| Working Modes | Range Extender |
| Reception Sensitivity | 5GHz: 11ax HE20 MCS0：-93dBm, 11ax HE20 MCS11：-62dBm 11ax HE40 MCS0：-90dBm, 11ax HE40 MCS11：-59dBm 11ax HE80 MCS0：-87dBm, 11ax HE80 MCS11：-56dBm 11ax HE160 MCS0：-84dBm, 11ax HE160 MCS11：-53dBm 2.4GHz: 11ax HE20 MCS0：-95dBm, 11ax HE20 MCS11：-64dBm 11ax HE40 MCS0：-92dBm, 11ax HE40 MCS11：-62dBm |
| Wireless Functions | Smart Antennas Enable/Disable Wireless Radio DFS (the latest firmware and hardware version is required) Access Control LED Control Power Schedule Wi-Fi Coverage |
| Wireless Security | WPA/WPA-PSK2 encryptions, WPA3 |
| Transmission Power | FCC: 2.4GHz < 30dBm, 5GHz < 30dBm |
| Mesh Technology | EasyMesh-Compatible |
| OTHERS | |
|---|---|
| Certification | FCC, RoHS |
| Package Contents | Wi-Fi Range Extender Archer Air E5 Quick Installation Guide Power Adapter Plastic Bracket Level Installation Accessories |
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser |
| Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
