Description
| P/N | PS-TPD-1000FNFAGE-4 |
|---|---|
| watts | 1000W |
| Model | TPD-1000AH3FCG |
| Max. Output Capacity | 1000W |
| COULEUR | Black |
| Dimension ( W / H / D ) | 150mm(W) x 86mm(H) x 160mm(D) |
| Weight | 1.72 KG |
| PFC (Power Factor Correction) | Active PFC |
| Power Good Signal | 100-150 msec |
| Hold Up Time | > 17msec at 100% of full load |
| Input Current | 13.0A / 6.5A |
| Input Frequency Range | 50/60Hz |
| Input Voltage | 100V – 240V~ |
| Operating Temperature | 0°C to + 40°C |
| Operating Humidity | 20% to 90%,non-condensing |
| Storage Temperature | -20°C to + 70°C |
| Storage Humidity | 5% to 95%, non-condensing |
| SYSTÈME DE REFROIDISSEMENT | 13.5cm fluid bearing fan |
| Efficiency | Meet 80 PLUS®Gold at 115Vac input. |
| MTBF | 100,000 hrs minimum |
| Safety Approval | CE/UKCA/cTUVus/TÜV/FCC/IC/BSMI/EAC/CB/CCC |
| PCI-E Connector | PCIe 6+2pin x 4 PCIe 12+4pin x 1 |
| Protection | OCP, OVP, UVP, OPP, SCP, OTP |
