Description
Overview
Dimensions:
98 x 98 x 30 mm
(3.9 x 3.9 x 1.2″)
Max. WAN Port Count: 1
Default WAN Ports: (1) GbE RJ45
Port Layout:
-
1 GbE RJ45: 2 (1G/100M/10M)
IDS/IPS Throughput: 1 Gbps
Form Factor: Compact desktop
Security
-
Stateful Firewall ✓
-
Application-Aware Layer 7 Firewall ✓
-
DPI & Traffic Identification ✓
-
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) ✓
-
Content Filtering ✓
-
Intrusion Prevention (IPS/IDS) ✓
-
Ad Blocking ✓
VPN & SD-WAN
-
License-Free SD-WAN ✓
-
Site-to-Site VPN:
-
Site Magic ✓
-
IPsec ✓
-
OpenVPN ✓
-
-
VPN Server:
-
Teleport Zero-Configuration VPN ✓
-
WireGuard ✓
-
OpenVPN ✓
-
L2TP ✓
-
-
VPN Client:
-
OpenVPN ✓
-
WireGuard ✓
-
Networking
-
Dynamic Routing: OSPF ✓
-
Advanced QoS ✓
-
Multicast DNS (mDNS) ✓
-
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) ✓
-
Integrated RADIUS Server ✓
-
RADIUS over TLS (RadSec) ✓
-
Additional Internet Failover with UniFi LTE Backup ✓
-
Internet Quality and Outage Reporting ✓
-
Policy-based WAN and VPN Routing ✓
-
Customizable DHCP Server ✓
-
IPv6 ISP Support ✓
Hardware
-
Max. Power Consumption: 3.83W
-
Power Method: USB Type-C (5V DC/3A)
-
Power Supply: USB Type-C (5V DC/3A) (Adapter included)
-
Supported Voltage Range: 100—240V AC
-
Processor: Dual-core ARM® Cortex®-A53 at 1 GHz
-
System Memory: 1 GB
-
Weight: 320 g (11.3 oz)
-
Enclosure Material: Polycarbonate
Management & Indicators
-
Ethernet
-
Bluetooth
-
LEDs: Ethernet ✓
-
Button: (1) Factory-reset
Environmental
-
Ambient Operating Temperature: -10 to 40° C (14 to 104° F)
-
Ambient Operating Humidity: 5 to 95% noncondensing
Compliance
-
NDAA Compliant ✓
-
Certifications: CE, FCC, IC, Anatel
Software
-
Application Requirements: UniFi Network Version 8.3.32 and later
