Description
| Mechanical | |
|---|---|
| Model | INS-3AF-O-G |
| Dimensions | Without RJ45 cable: Ø 30.2 x 166 mm (Ø1.2 x 6.5″) With RJ45 cable: Ø30.2 x 366.6 mm (Ø 1.2 x 14.4″) |
| Weight | 90 g (3.2 oz) |
| Networking interface | (1) GbE RJ45 port (PoE in) (1) GbE RJ45 port (PoE out) |
| Power method | 24V passive PoE (Pairs 4, 5+; 7, 8 return) |
| Power input | PoE, 48V DC, 0.5A |
| Max. power output | 24V DC, 0.5A |
| Ethernet ESD/surge protection | ±15kV |
| Ambient operating temperature | -30 to 70° C (-22 to 158° F) |
| NDAA Compliant | Ye |
