| DecodingFormat |
Ultra 265, H.265, H.264 |
| DecodingCapability |
NVR302‑09S2:2 x 4K@30, 3 x 5MP@30, 4 x 4MP@30, 5 x 3MP@30, 8 x 1080P@30, 9 x 1080P@25 |
| AudioCompression |
G.711A, G.711U |
| Network |
Description |
| IncomingBandwidth |
160Mbps |
| OutgoingBandwidth |
64Mbps |
| RemoteUsers |
128 |
| Protocols |
TCP/IP;P2P;UPnP;NTP;DHCP;PPPoE;HTTP;HTTPS;DNS;DDNS;SNMP;SMTP;RTSP |
| Browser(Plugin) |
Windows:IE(IE10/11), Firefox (version 52.0 and above), Chrome(version 45 and above), Edge(version 79 and above) |
| Video/AudioInput |
Description |
| IPVideoInput |
NVR302‑09S2:9‑ch |
| RCAAudioInput |
1‑ch |
| Video/AudioOutput |
Description |
| HDMIOutput |
HDMI:4K(3840×2160)/30Hz, 1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
| VGAOutput |
VGA:1920×1080/60Hz, 1920×1080/50Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
| RCAAudioOutput |
1‑ch |
| LiveviewDisplay |
NVR302‑09S2:1/4/6/8/9 |
| CorridorModeScreen |
NVR302‑09S2:3/4/5/7/9 |
| Two-wayAudio |
Description |
| Two-wayAudio |
1‑ch, RCA(Using the audio input and output) |
| Snapshot |
Description |
| FTP/Schedule/EventSnapshot |
4‑ch snapshot, up to D1 resolution |
| Recording |
Description |
| RecordingResolution |
8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/2CIF/CIF |
| SynchronousPlaybackinLocal |
NVR302‑09S2:9‑ch |
| Smart |
Description |
| VCADetectionbyIPC |
Face Detection;SIP(Intrusion Detection, Cross Line Detection, Enter Area, Leave Area);Ultra Motion Detection(UMD);People Counting(People Flow Counting, Crowd Density Monitoring) |
| VCASearch |
Motor Vehicle Search;Non‑Motor Vehicle Search;Human Body Search;General Search;People Counting Report |
| SmartbyIPC |
Total 8‑ch(Face Detection, SIP, UMD) |
| Alarm |
Description |
| GeneralAlarm |
Defocus Detection;Scene Change Detection;Object Left Behind;Object Removed;Auto Tracking;Motion Detection;Tampering;Human Body Detection;Video Loss;Alarm Input;Audio Detection |
| AlertAlarm |
IP Conflict;Network Disconnected;Disk Offline;Disk Abnormal;Illegal Access;Hard Disk Space Low;Hard Disk Full;Recording/Snapshot Abnormal |
| HardDisk |
Description |
| SATA |
2 SATA Interfaces |
| Capacity |
Up to 10TB for each HDD(The maximum HDD capacity varies with environment temperature) |
| ExternalInterface |
Description |
| NetworkInterface |
2 RJ45 10M/100M/1000M self‑adaptive Ethernet Interface |
| USB |
Front panel: 1 x USB2.0;Rear panel: 1 x USB3.0, 1 x USB2.0 |
| RS485 |
N/A |
| RS232 |
N/A |
| AlarmIn |
N/A |
| AlarmOut |
N/A |
| PowerSupply |
DC 12V/3A |
| PowerSwitch |
Support |
| WorkingEnvironment |
Description |
| WorkingTemperature |
‑10 °C ~ 55 °C (14 °F ~ 131 °F) |
| WorkingHumidity |
≤ 90% RH (non‑condensing) |
| PowerConsumption(withoutHDD) |
≤ 15W |
| Dimensions |
Description |
| Weight(withoutHDD) |
≤ 2.48Kg (5.47lb) |
| Dimensions |
380mm × 315mm ×53mm (15.0″×12.4″×2.1″) |
| Certification |
Description |
| Certification |
CE;FCC;UL;RoHS;WEEE |
| CE |
EN 55032, EN 61000‑3‑3, EN IEC 61000‑3‑2, EN 55035 |
| FCC |
Part15 Subpart B |
