Description
Parameters
- Display2.4-inch TFT LCD Color Screen
- Fingerprint Capacity (optional)3,000
- Card Capacity5000(Optional) ID / IC / HID Prox / HID iclass card
- Transaction Capacity100,000
- SensorZK Optical Sensor
- Algorithm VersionZK Finger V10.0
- CommunicationRS232 / 485*, TCP / IP, USB-host
- Access Control Interface3rd Party Electric Lock, Door Sensor, Exit Button, Alarm, Doorbell
- Wiegand SignalInput, Output, SRB
- FunctionsDST, Record Query, Anti-passback, External RS485 fingerprint reader, Printer(Optional), WIFI(Optional), https(Optional)
- Power Supply12V DC, 3A
- Operating Temperature0 °C – 45 °C
- Operating Humidity20% – 80%
- SDK and SoftwareAC push, ZKBio CVAccess / TA push, ZKBioTime8.0 / Standalone SDK, ZKAccess3.5
- Dimension80 × 183 × 42mm (W*D*H)
