Description
Technical Specifications
| Attribute | Details |
|---|---|
| Launch Date | Q1’2010 |
| Status | Discontinued |
| Market Segment | Server / Enterprise |
| Socket | FCLGA1366 / LGA1366 |
| TDP | 80 W |
| Tcase Max | 77.6°C |
| Package Size | 42.5mm x 45mm |
| Embedded Options Available | Yes |
| Max CPU Configuration | 2 CPUs |
Performance
| Attribute | Details |
|---|---|
| Total Cores / Threads | 4 Cores / 8 Threads |
| Base Frequency | 2.40 GHz |
| Max Turbo Frequency | 2.66 GHz |
| Cache | 12 MB Intel® Smart Cache |
| Bus Speed | 5.86 GT/s QPI |
| QPI Links | 2 |
Memory Support
| Attribute | Details |
|---|---|
| Max Memory Size | 288 GB |
| Memory Types | DDR3-800 / 1066 |
| Memory Channels | 3 |
| Max Memory Bandwidth | 25.6 GB/s |
| Physical Address Extensions | 40-bit |
| ECC Memory Supported | Yes |
Advanced Technologies
| Technology | Supported |
|---|---|
| Intel® Turbo Boost Technology (1.0) | Yes |
| Intel® Hyper-Threading Technology | Yes |
| Intel® 64 | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® SSE4.2 |
| Idle States | Yes |
| Enhanced Intel SpeedStep® Technology | Yes |
| Intel® Demand Based Switching | Yes |
| Thermal Monitoring Technologies | No |
Security & Virtualization
| Feature | Supported |
|---|---|
| Intel® AES New Instructions | Yes |
| Intel® Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel® Virtualization Technology (VT-x) | Yes |
| Intel® VT-d (Directed I/O) | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
