Description
General Information
| Attribute | Details |
|---|---|
| Launch Date | Q1’17 |
| Status | Discontinued (Support ended Mar 31, 2024) |
| Socket | FCLGA1151 |
| TDP | 65 W |
| Max Operating Temp (TJUNCTION) | 100°C |
| Use Conditions | PC / Client / Tablet |
Core Architecture
| Total Cores | 4 |
|---|---|
| Total Threads | 4 |
| Base Frequency | 3.50 GHz |
| Max Turbo Frequency | 4.10 GHz |
| Cache (L3) | 6 MB Intel® Smart Cache |
| Bus Speed | 8 GT/s |
Memory Support
| Max Memory Size | 64 GB |
|---|---|
| Memory Types | DDR4-2133/2400, DDR3L-1333/1600 |
| Memory Channels | 2 |
| ECC Memory Support | No |
Integrated Graphics
| GPU Name | Intel® HD Graphics 630 |
|---|---|
| Base Frequency | 350 MHz |
| Max Dynamic Frequency | 1.15 GHz |
| 4K Support | Yes @ 60Hz |
| Max Displays Supported | 3 |
| Max Resolutions | HDMI: 4096×2304@24Hz DP/eDP: 4096×2304@60Hz |
| DirectX/OpenGL Support | 12 / 4.5 |
Expansion & I/O
| PCI Express Revision | 3.0 |
|---|---|
| PCIe Configurations | 1×16, 2×8, 1×8+2×4 |
| Max PCIe Lanes | 16 |
Package Details
| Package Size | 37.5 mm x 37.5 mm |
|---|---|
| Thermal Solution Spec | PCG 2015C (65W) |
| Max CPU Configuration | 1 |
Advanced Technologies
-
Intel® Turbo Boost Technology 2.0
-
Intel® Optane™ Memory Support
-
Intel® SpeedStep®, Thermal Monitoring
-
Transactional Synchronization Extensions
-
Instruction Set: 64-bit
-
Instruction Set Extensions: SSE4.1, SSE4.2, AVX2
Security & Virtualization
-
Intel® AES-NI, Secure Key, OS Guard
-
Intel® Virtualization Technology (VT-x, VT-d, EPT)
-
Intel® SGX, MPX, Boot Guard
-
Intel® Trusted Execution Technology
-
Intel® Identity Protection Technology
-
Intel® vPro® Platform / SIPP
