Description
| Wireless | |
| Standards | WiFi 6 |
| IEEE 802.11ax/ac/n/a 5GHz | |
| IEEE 802.11ax/n/b/g 2.4GHz | |
| Signal Rate | AX1800 |
| 5GHz:1201Mbps (802.11ax) | |
| 2.4GHz:574Mbps (802.11ax) | |
| Mesh Network Standard | Easy Mesh |
| WiFi Range | 2.4-2.4835GHz and 5.150~5.85GHz 3 Bedroom Houses
4×Fixed High-Performance Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas Beamforming Concentrates wireless signal strength towards clients to expand WiFi range Improves transmission power to strengthen signal coverage |
| WiFi Capaciyt |
Dual-Band:
Allocate devices to different bands for optimal performance OFDMA： Simultaneously communicates with multiple Wi-Fi 6 clients Airtime Fairness：Improves network efficiency by limiting excessive occupation 4 Streams：Connect your devices to more bandwidth |
| Work Modes | Router Mode, Access Point Mode |
| Hardware | |
| Processor | 880MHz Dual-Core CP |
| Ethernet Ports | 1*Gigabit WAN Port
1*Gigabit LAN Port |
| LED Indicatiors | SyS,LAN,Mesh(wps),WAN |
| Button | Mesh,Reset |
| Antenna | 4*Internet fixd 5dBi antenna |
| Power Supply | 12V/1A |
| Security | |
| WiFi Encryption | WPA,WPA2,WPA/WPA2,WPA3 |
| Network Security | Access Control,Application Layer Gataway |
| Guset Network | 1*5GHz Guest Network
1*5GHz Guest Network |
| Software | |
| Protocols | IPv4,IPv6 |
| WAN Types | Dynamic IP,Static IP,PPPoE,PPTP,L2TP |
| Quality of Service | QoS by Device |
| NAT Forwarding | Port forwarding,port triggering,DMZ,UPnP |
| IPTV | IGMY Proxy,IGMP Snooping,Bridge,TAG VLAN |
| DHCP | Address Reservation,DHCP Client List,Server |
| DDNS | NO-IP,DynDNS |
| Physical | |
| Dimensions(W*D*H) | 104*104*96mm |
| Package Contents | WiFi 6 Mesh Router
Power Adapter Quick Installation Guide |
| Other | |
| Systems Requirements |
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access) |
| Certifications | FCC,CE,RoHS |
| Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| Test DATA | |
| WiFi Transmission Power | CE:
<20dBm(2.4 GHz) <23dBm(5.15 GHz~5.25 GHz) FCC: <30dBm(2.4 GHz & 5.15 GHz~5.825 GHz) |
