Description
6-Port 100Mbps, 4 of the ports support PoE/PoE+ power supply.
Max PoE power budget is 54W, Steel Case
Product Information
Product Category
Product Category
- Layer 2
Hardware Specifications
Product Information
Warranty
- 1 year
Port Specifications
Total number of RJ45 ports
- 6
Number of 10/100BASE-T ports
- 6
Power Supply and Consumption
Number of PoE Out ports
- 4
Number of PoE/PoE+ Out ports
- 4
PoE budget
- 54 W
PoE power pins
- 1–2 (+), 3–6 (-)
System Specifications
Forwarding rate
- 0.8 Mpps
Switching capacity
- 1.2 Gbps(bit/s)
Environment and Reliability
Operating temperature
- 0°C to 45°C (32°F to 113°F)
Software Specifications
Basic Configurations
PoE watchdog
- Yes
Security
Port isolation
- Yes
