Description
24*10/100Mbps Base-TX Ports(POE, Max PoE budget:180W)
,2*10/100/1000Mbps Base-T with 1Combo Uplink Ports
Product Information
Product Category
Product Category
- Layer 2
Hardware Specifications
Product Information
Warranty
- 1 year
Port Specifications
Total number of RJ45 ports
- 26
Total number of optical ports
- 1
Number of 1GE combo ports
- 1
Number of 1GE SFP ports
- 1
Number of 10/100BASE-T ports
- 24
Number of 10/100/1000BASE-T ports
- 2
Power Supply and Consumption
Number of PoE Out ports
- 24
Number of PoE/PoE+ Out ports
- 24
PoE budget
- 180 W
PoE power pins
- 1–2 (+), 3–6 (-)
System Specifications
Forwarding rate
- 6.55 Mpps
Switching capacity
- 8.8 Gbps(bit/s)
Environment and Reliability
Operating temperature
- 0°C to 45°C (32°F to 113°F)
Software Specifications
Security
Port isolation
- Ports 1 to 24 cannot communicate with each other, but they can communicate with ports 25 and 26.
